| Material: | High Chrome Cast Iron,A05,A49 | OEM: | YES |
|---|---|---|---|
| ODM: | YES | ||
| High Light: | Warman Slurry Pump Spare Parts,Slurry Pump Spare Parts Anti Abrasive,Warman Slurry Pump Volute Liner |
||
High chrome Anti-abrasive and anti-corrosion slurry pump volute liner
The INTRODUCTION of the volute liner
|
Process
|
sol investment casting + machining
|
|
Main Products
|
Valve parts include ball valve, butterfy valve, plug valve, check valve, safety valve etc.
|
|
Pump parts include diaphragm pump, centrifugal pump, vacuum pump, water pump etc.
|
|
|
Impeller include closed impeller, semi-closed impeller and open impeller.
|
|
|
Flare and burner parts.
|
|
|
Food machinery parts include meat grinding machining and beer machine etc.
|
|
|
Other mechanical parts
|
|
|
Material
|
Stainless steel include CF8,CF8M,CF3,CF3M,AISI304,AISI316,SCS13,SCS14,1.4308,1.4408,HK etc.
|
|
Duplex stainless steel include 2205,2507,2304,1.4410,1.4417,1.4460 etcDuplex stainless steel include 2205,2507,2304,1.4410,1.4417,1.4460 etc
|
|
|
Alloy steel include 25CrMO4,1.7225 etc
|
|
|
Carbon steel include WCB, LCB, 1020, 1.0619.
|
|
|
Standard
|
JIS,ASTM,AISI,DIN,BS, EN, SS etc
|
|
Inspection
|
Chemical Analysis
|
|
Dimension and surface inspection
|
|
|
PT,MT,RT,ET
|
|
|
Mechanical Property ,balancing test, pressure test etc.
|
|
|
OEM and ODM
|
|
|
Packing
|
European wooden case+carton
|
The application of the volute liner
Warman slurry pump
Warman sand gravel pump
other brand slurry pump and sand gravel pump
mining pump
The Spcrtion of the volute liner
| Part Name | Material | Specification | HRC | Application | OEM Code |
| Liners | Metal | AB27: 23%-30% chrome white iron | ≥56 | Used for higher wear condition with pH between 5 and 12 | A05 |
| AB15: 14%-18% chrome white iron | ≥59 | Used for higher wear condition | A07 | ||
| AB29: 27%-29% chrome white iron | 43 | Used for lower pH condition especially for FGD. It also can be used for low-sour condition and desulfuration installation with pH no less than 4 | A49 | ||
| AB33: 33%-37% chrome white iron | It can transport oxygenated slurry with pH not be less than 1 such as phospor-plaster, nitric acid, vitriol, phosphate etc. | A33 |
The Feature of the volute liner
Warman slurry pump
Warman sand gravel pump
other brand slurry pump and sand gravel pump
mining pump
pc of volute liner
