| Spare Parts: | Impeller, Cover Plate Liner, Frame Plate Liner, Packing | Theory: | Centrifugal Single Stage |
|---|---|---|---|
| Outlet Size: | 1''-18'' | Usage: | Transferring Sludge At Mine, Civil Works |
| OEM: | Availiable | Material: | Cr27 Cr28 Chrome Alloy/A05/rubber |
| High Light: | Slurry Pump Spares HRC60,Slurry Pump Spares Cover Plate Liner,HRC60 slurry pump impeller |
||
River And Sea Dredging Pump Anti-Wear And Corrosion-Resistant Long Life High Chrome Cast Iron Pump Parts
Intorduction
The main wet parts of our slurry pumps are made of high chrome alloy(made of Cr 26-28%, with hardness HRC60+) wear resistant metal, and it's made as per standard which can be interchangeable with famous brand pumps.We can also accept OEM services, which means we can produce it as your own design.
The Features:
1. The wet parts for slurry pump are made of wear-resistant chromium alloy.
2. Slurry pump's bearing assembly use cylindrical structure,adjusting the space between impeller andfront liner easily, they can be removed completely when being repaired. Bearing assembly usegrease lubrication.
3. The shaft seal could use the packing seal, expeller seal and mechanical seal.
4. The discharge branch can be positioned at intervals of 45 degrees by request and oriented to anyeight positions to suit installations and applications.
5. There are the drive types, such as V belt drive, gear reducer drive, fluid coupling drive, frequencyconversion drive devices for the slurry pump.
Materials
High chrome alloy: A05, A07, A49, etc.
Natural rubber: R08, R26, R33, , etc.
| No. | ITEM | MATERIAL |
| 1 | Impeller | High-chrome alloy |
| Rubber | ||
| 2 | Volute casing | High-chrome alloy |
| 3 | Front liner plate | High-chrome alloy |
| Rubber | ||
| 4 | Rear liner plate | High-chrome alloy |
| Rubber | ||
| 5 | Liner | High-chrome alloy |
| 6 | Expeller | High-chrome alloy |
| 7 | Shaft sleeve | 3Cr13 |
| 8 | Water-seal ring | High-chrome alloy |
| 9 | Shaft | 45#steel quenching And high temperature tempering |
| 10 | Bearing housing | Gray iron |
| 11 | Expeller ring | High-chrome alloy |
| Rubber | ||
| 12 | Front casing | Gray iron or Nodular cast iron |
| 13 | Rear casing | Gray iron or Nodular cast iron |
Application
The part of the slurry pump is made of high-chromium wear-resistant alloy or natural rubber material, and its wear resistance has won international praise and recognition. Slurry pump is an ideal tool for conveying abrasive and corrosive materials
